KIKUSUI PMX500-0.1A Compact DC Power Supply (500V/ 0.1A)

Input voltage: 100 ± 10% VAC

Constant voltage (CV):

+ Output: 0 ~ 500V

+ Ripple: 10 mVrms

+ Line regulation: ±30 mV

+ Load regulation: ±30 mV

Constant current (CC):

+ Output: 0 ~ 0.1A

+ Ripple: 1 mArms

+ Line regulation: ±1 mA

+ Load regulation: ±3 mA

Weight: 6kg (13.23 lbs)

Interface: RS232C, USB, LAN, GPIB (option)

Accessories: Power cord, packing list, quick reference, safety precautions, CD-ROM

Option: Rack mount adapter, blank panel, connector kit, terminal unit

Detail

Datasheet


Manual
