PCE CT 40 Coating Thickness Meter (0 ~ 5000 µm)

  • Manufacturer: PCE
    Model: CT 40
    Origin: Germany
    Guarantee: 12 month
    • Request a Quotation Request a Quotation
  • 14,065,071 VND
  •  Call for best price

    Hotline: (+84) 867820758

    Phone+84 (24)62923267

Specification

Measurement range: 0 to 5000 µm / 200 mils

Measurement values: from 0.0 ... 999 µm / from 1.00 mm ... 5.00 mm

0.0 mils ... 40 mils / 0.04 in ... 0.2 in

Measuring on: only ferrous

Resolution:

0.1 µm in the range 0.0 ... 99.9 µm

1 µm in the range 100 ... 999 µm

0.01 mm in the range 1.00 ... 5.00 mm

respectively

0.01 mils in the range 0.00 ... 9.99 mils

0.1 mils in the range 10.0 ... 99.0 mils

1.0 in the range 100 ... 200 mils

Accuracy of repeat measurements: ±(1 µm +2 %) of 0 µm ... 999 µm / 40 mils

±3.5 % of 1001 µm ... 5000 µm / 40 mils ... 200 mils

Minimum area of measurement: 10 mm x 10 mm / 0.4 in x 0.4 in

Minimal radial curvature:

convex: 5 mm / 0.2 in

concave: 30 mm / 1.2 in

Minimum base material thickness type F: 0.2 mm / 0.001 in

type N: 0.05 mm / 0.002 in

Display: LCD with 4 digits

Operating temperature: 0° C ... 60° C / 32° F ... 140° F

Power: 9 V battery (included)

Dimensions:

118 mm x 58 mm x 38 mm

4.6 in x 2.3 in x 1.5 in

Weight: 150 g / 0.33 lbs with battery


Delivery contents

1 x PCE-CT 40 Material Thickness Meter

1 x set of calibration standards

1 x carrying case

1 x 9 V battery

1 x user manual

Details

Manual


Datasheet
