RenThang SMT-401 SMT Semiautomatic Pick and Place Machine
-
Manufacturer: REN THANG Model: SMT-401 Origin: Taiwan Guarantee: 12 month -
Contact
-
Call for best price
Hanoi: (024) 35.381.269
Đà Nẵng: (0236) 3 74 77 11
TP.HCM: (028) 38.119.636
- Quality Engagement
- Easy change and return
- Delivery Avaliable
- Favorable payment
Manufacturer: RenThang
Model: SMT-401
Origin: Taiwan
Warranty: 12 months
Power: AC 220 V 50 / 60HZ ( depends on Country)
Weight: 22 KGS
Dimension:800x 720x 300mm
Air Source: 4 ~ 5Kg / squared cm
Feeder:16 Sets
Material Box: 90 pieces
MAX. PCB Working Size: 250 x300mm
Capacity: 20~50pcs / Minute
FEATURES:
Available for sample design, especially for changeable small quantity multi style production.
Sucking quickly the SMT component and taping on the PC board.
Sliding axial X andY. keep the SMT component will not vibration when it is Taped on the board.
Feeder frame could turn around 360 degree, 90 kinds of components could be operated.
16 setsSMT tape reel material could be loaded.
Suitable for anyreel size. Vacuum pipe could suck different size SMTcomponent.
Several machine connected could offer bigvolume and efficiency production only small vestment.
