TECLOCK CD-35S Bore Gauge (18-35mm)
-
Manufacturer: TECLOCK Model: CD-35S Origin: Japan Guarantee: 12 month -
Contact
-
Call for best price
Hanoi: (024) 35.381.269
Đà Nẵng: (0236) 3 74 77 11
TP.HCM: (028) 38.119.636
- Quality Engagement
- Easy change and return
- Delivery Avaliable
- Favorable payment
Manufacturer: TECLOCK
Model: CD-35S
Origin: Japan
Warranty: 12 months
Measuring Range: 18-35 mm
Effective Measuring Range: 1.2 mm
Probe Depth: 50 mm
Total Range Error: 0.002 mm
Measuring Force: ≤ 4 N
Number of Anvils: Incream 9pcs./2mm
Number of Washers: 2
Weight: 150 g
Catalog
• Compliance with JIS B 7515A.
• Anvil and Contact point are using the carbide ball.
• The measuring depth can be extend using the extension rod to measure a deep hole.
