TOB TOB-V-125 Power Bank Tester (0-10V)
Manufacturer: TOB Model: TOB-V-125 Origin: China Guarantee: 12 Month - Request a Quotation
- Contact
Call for the best price
Hanoi city: (024) 35.381.269
Danang city: (023) 63.747.711
Bac Ninh city: (0222)730.39.68
HCM city: (028) 38.119.636
Open circuit voltage V1: Output voltage of the power of the no load condition. Range : 0-10V
Min load voltage V2
A voltage with a relatively small load current power supply.
Range : Current : 50-5000mA, Time : 0-5000mS, Voltage : 0-10V
Middle load voltage V3
A voltage with a relative moderate load current power supply
Range : Current : 50-5000mA, Time : 0-5000mS, Voltage : 0-10V
Max load voltage V4
A voltage with a relatively large load current power supply
Range : Current : 50-5000mA, Time : 0-5000mS, Voltage : 0-10V
Charge current
Test the charge current for the power bank on a set voltage.
Range : Current : 50-5000mA, Time : 0-9999mS, Voltage : 0-10V
Short circuit protection time
In the case of short circuit, reaction time of power bank on short circuit protection function.
Range : Time : 0-9999mS
A B Test mode: Suitable for power bank with two output.
Over discharge current: Protect current. Range : 0-10A
Dimension: 290*270*100mm
Weight: 5kg
