TOB BE-HLK-150M3 Battery Temperature Cycling Testing Machine (150L, -40℃~+150℃)

Within Volume: 150L

Within Feet(cm): 50*60*50

Working environment: +5~+35℃

Heater: Nickel-cadmium alloy strip heater

Blower: Centrifugal fan

Airflow mode: Broadband type forced air cycle (up out,down in)

Condensing mode: Air-cooled or water-cooled

Temperature range: -40℃~+150℃

Temperature fluctuation: ±0.5℃

Rise time: -40~+80℃<30min,4℃/min Average,rise and fall speed customizable

Fall time: +80~-40℃<30min,4℃/min Average,rise and fall speed customizable

Box material

Inside:Mirror stainless steel

Outside:Mirror stainless steel or Steel spray

Insulation material: Rigid polyurethane foam

Controller

“8”show:TEMI880 Color touch smart programmable controller(Chinese-English Convertible)

“3”show:TEMI300 LCD keypad controllers(English Display)

Cooling system: France Taikang hermetic compressors(Environmentally friendly refrigerant)

Protection device: Compressor overheating, over-current, over-voltage, heating nothingr burning, over temperature alarm system inside

Power: AC3∅5W 380V

Standard configuration: A viewing window, ∅ 50mm Test hole, Sample holder 2 set, Inside lights 4 Mobile working wheels

Option: Communication port, Logger, Built-in glass doors or operation hole
