ZHUOMAO ZM-R5860C BGA rework station with camera monitor and equipped with soldering iron

  • Manufacturer: Seamark ZM
    Model: ZM-R5860C
    • Request a Quotation Request a Quotation
  • Contact
  •  Call for best price

    Hotline: (+84) 867820758

    Phone+84 (24)62923267

Manufacture: ZHUOMAO
Model: ZM-R5860C


Made in: China

Total Power: 4850W
Top heater: 800W
Bottom heater: 2nd  heater 1200W,3rd IR heater 2700W
Power: AC220V±10%     50/60Hz
Dimensions: L635*W600*H560 mm
Positioning: V-groove, PCB support can be adjusted in any direction and with external universal fixture
Temperature control: K-type thermocouple (Closed Loop), heating independently, temperature precision within ±3 degree
PCB size: Max 410*370mm      Min 20*20mm
Electrical materials: Taiwan touch screen + Delta PLC + high precision intelligent temperature control module
Net weight: 40KG
