Yamato DNE411 強制対流オーブン (90L, 1.1 kW)

  • 生産者:Yamato
    Model: DNE411
    P/N: 212819
    品物を保証します: 12 Month
    • 要件クオート Request a Quotation
  • 連絡先
    • カートへ追加
    • 今すぐ注文
  • 전화번호: いい価格のため、連絡しなさい
    ホットライン: (+84) 968060220
    電話番号: +84 (24)62923267

Circulation method: Forced air circulation

Operating temperature range: RT +20 to 210°C

Temp. control accuracy: ±0.5°C (at 210°C) JTM K05

Temp. distribution accuracy: ±2.0°C (at 210°C) JTM K05

Max. temp. reaching time: Approx. 60 min

Interior/Exterior material: Stainless steel /Electro-galvanized steel sheet with epoxy and melamine resin baking finish

Insulation material: Glass wool

Heater: Stainless pipe heater 1.1 kW

Fan type / Motor: Scirocco fan / Condenser type motor

Cable port: 33mm I.D. (the right, upper) 1pc.

Air in-take port: 33mm I.D. (the right, lower) 1pc.

Exhaust port: 33mm I.D.×2 (the top)

Temp. controller: PlD control by microprocessor

Internal dimensions (W×D×H): 450×450×450 mm

External dimensions (W×D×H): 580×645×860 mm

Internal capacity: 90L

Power supply: AC 220V Single-phase 6A

Weight: 63 kg

Accessories:

- Shelf plate: Stainless steel, 2 pcs

- Shelf bracket: 4 pcs. (1 pair - 2 pcs. is fixed)
