Yamato IJ201 低温恒温器 (27L)

Type: Forced convection

Operating Temperature Range: 5～60℃（at room temp.25℃）

Temp. Control Accuracy: ±0.5℃（at 37℃）

Temp. Distribution Accuracy: ±1.0℃（at 37℃）

Time to Max. Temp.: 20～60℃　50min.

Time to Lowest Temp.: 20～5℃　120min.

Interior: Stainless steel

Heater: Mica heater 150W

Temp. Control Method: PID

Observation window: 180×180mm

Cable hole:  φ30mm, Right side of the main body

Accessories: Shelf(Stainless punching metal) 2pcs., Shelf support 4 pcs., Receiver for drain 1pc.

Internal dimensions（W×D×H mm）: 300×300×300mm

External dimensions（W×D×H mm）: 580×417×437mm

Remarks(dimensions): 27L

Power Source: AC115V/AC220V single phase with step-down transformer

Weight: 25kg
