Yamato SN210 Steam Sterilizer (20L)

System: Automatic high-pressure steam sterilization

Operating temperature range: 45~135℃ 45~80℃(Preheating temperature)/45~60℃(Heat-retention process)/65~100℃(Solution process)/105~135℃(Sterilization)

Max. working pressure: 0.255MPa

Ambient temperature: 5~35℃

Lid: Manual upward opening with an interlock for safety

Heater: 100V, 600W×2

Exhaust valve: One exhaust valve and one slow release valve

Connection ports for optional accessories: Total 3 ports. Female thread for sample temp. sensor (1/4" ), Female thread for chamber temp. sensor (1/4" ), Female thread pressure sensor (Branching from the solenoid valve tubing)

Cooling fan: Axial fan motor

Temp. controller: PID control by microprocessor

Accessories: 2 pcs. stainless steel mesh basket (Dia.209×D204mm), OSM-60/Vapor cup×1, Drain bottle×1, Drain board×1, Filter×1

Internal dimensions(φ×H mm): φ240×445mm

External dimensions(W×D×H mm): 400×530×840mm

Remarks(dimensions): Internal capacity 20L

Power Source: AC200~240V Single phase

Weight: 65kg
