AP&T AP-DJ2706 六风扇顶部离子风机 (4 electrode pins, ＜77W, 6 fan)

Input voltage: DC24V (RJ45 interface)/Three in one socket (220VAC 50/60Hz)

Input current: ＜0.35A AC

Output voltage: DC±4.5KV - ±5.5KV

Power: ＜77W

Ion emission: DC

Emitter electrode: Tungsten alloy

Discharge range: 750x1500mm

Discharge speed: ≤2.5s (450mm from the air outlet)

Ion balance: ≤/±15V/

Alarm indication:

Power on/clean operation-blue light flashes

Normal work-green light  (always in monitoring state)

Fan alarm - red light is always on

High voltage abnormally-red light flashes

Blue light flashes during infrared  debugging

Air volume: ≤93CFMx6

Noise: Single air outlet ≤45dbA (1000mm away from the air outlet)

Ozone thickness: ≤0.05ppm (1500mm away from the air outlet)

Communication method: RS485

Operating temperature: 0-50℃

Working humidity: ＜70%RH

Dimensions: 1553x154x114mm (LxWxH)
