Aqualabo PF-CAP-C-00160 氧光学数字传感器,裸线3m OPTOD (0,00 - 20,00 mg/L, 0,00 - 20,00 ppm, 0-200%)

TECHNICAL SPECIFICATIONS

Measure principle: Optical measure by luminescence

Measure ranges: 0,00 to 20,00 mg/L, 0,00 to 20,00 ppm, 0-200%

Resolution: 0,01

Accuracy: +/- 0,1mg/L, +/- 0,1 ppm, +/- 1 %

Response time:  90% of the value in less than 60 seconds

Frequency of recommended measure: >5 s

Water move: No necessary move

Temperature compensation: Via NTC

Stocking temperature: -10°C to + 60°C

Signal interface: Modbus RS-485 (standard) and SDI-12 (option)

Sensor power-supply:  5 to 12 volts

Consumption: Standby 25 μA

                       Average RS485 (1 measure/ seconde) : 4,4 mA

                       Average SDI12 (1 measure/ seconde) : 7,3 mA

                       Current pulse : 100 mA

Sensor

Dimensions: Diameter : 25 mm ; length : 146 mm

Weight: Stainless steel version 450g (sensor + cable 3 m)

              Titanium version 300 g (sensor + cable 3 m)

Material: Stainless steel 316L, New : body in Titanium

Maximum pressure: 5 bars

Connection: 9 armoured connectors, polyurethane jacket, barewires or waterproof Fisher connector

Protection: IP68

For specific range please check the attachment below!

Details

Datasheet

Datasheet Oxygen Optical digital sensor OPTOD_2


Datasheet Oxygen Optical digital sensor OPTOD


Manual

User Manual Oxygen Optical digital sensor OPTOD
