METRIX OX5042B 便携式示波器 (2CH, 40MHz)

Number of channels: 2 channels

Resolution of the ADC: 9 bits

Maximum sampling frequency: 50 MS/s in real time / 1 converter per channel

Depth of acquisition memory: 2500 pts per channel

Vertical calibres: 5 mV to 200 V/div

BP at -3 dB: 40 MHz

Max input voltage: 600 VDC, 600 Vrms

Rise time: 8.75 ns

Input impedance: 1 MΩ ±0.5% approx. 17 pF

TIme base calibres: from 25 ns to 200 s/div

Trigger source: A,B

Trigger mode: Automatic / Triggered / One shot
