Suneast LD-400 Fully automatic PCB loader

Machine dimension(mm): 1475L*940W*1250H

PCB Size(mm):  Min:70L*70W*0.7H~  Max450L*320W*3H

Carrier size(Pallet size) (mm):    460L*400W*565H; Weight Approx 8.8kg

Approx machine weight:  200kg

Power:        0.2KW

Total allowed loading number of the carrier:        3

Conveying height:        900±20mm

Stepping choice:        10mm,20mm,30mm,40mm,50mm

Control mode:        PLC

Production cycle:        ≤10/s

Powersupply:        AC220V 50/60Hz

Gas pressure:        0.4~0.7MPa

Direction:        L to R(Options:R to L)
