Suneast UL-500 全自动PCB卸载机

Machine dimension(mm): 2240L*1070W*1250H

PCB Size(mm):  Min:70L*70W*0.7H~Max.530L*460W*3H

Carrier size (Pallet size) (mm): 535L*530W*570H; Weight Approx 12.3kg

Approx machine weight: 350kg

Power:   0.5KW

Total alowed loading number of the carrier:        3

Conveying height:        900±20mm

Stepping choice:        10mm,20mm,30mm,40mm,50mm

Control mode:        PLC

Production cycle:        ≤10/s

Power supply:        AC220V 50/60Hz

Gas pressure:        0.4~0.7MPa

Direction:        L to R (Options:R to L)
