Operating Wavelength: 1050 nm
ASE Center Wavelength: 1040 nm(b)
Operating Current (Max): 600 mA
3 dB Bandwidth: 85 nm
Saturation Output Power (@ -3 dB)(c,d): 17 dBm
SSmall Signal Gain (@ Pin = -20 dBm)(c,d): 28 dB
Noise Figure(c,d): 7.5 dB
Fiber Type: PM980-XP
(a) All specifications are typical unless otherwise noted.
(b) To guarantee a higher saturated output power of 17 dBm, the typical center ASE wavelength will be shorter than the operating wavelength of 1050 nm.
(c) Measured at 1054.7 nm
(d) Measured at the Operating Current
