Murata Electronics LBEE5PA1LD-005 Multiprotocol Modules Type 1LD Shielded ultra-small dual bandWi-Fi 11a/b/g/n/ac Bluetooth 4.2
Manufacturer: Murata Electronics Model: LBEE5PA1LD-005 - Contact
Call for the best price
Hanoi city: (024) 35.381.269
Danang city: (023) 63.747.711
Bac Ninh city: (0222)730.39.68
HCM city: (028) 38.119.636
Data Rate: 11 Mb/s, 54 Mb/s, 65 Mb/s
Frequency: 2.4 GHz
Dimensions: 8.9 mm x 7.8 mm x 1.2 mm
Output Power: 17 dBm
Qualification: AWS
Interface Type: GPIO, I2C, SPI, UART
Moisture Sensitive: Yes
Modulation Technique: CCK, DSSS, OFDM
Supply Voltage - Max: 3.6 V
Supply Voltage - Min: 1.8 V
Antenna Connector Type: External
Operating Supply Voltage: 3.3 V
Protocol - WiFi - 802.11: 802.11 a/b/g/n/ac
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth 4.2
