Weight: Approximately 26 lb (11.8 kg)
Dimensions: 7.875" W x 7.875" D x 8.5" H(200mm W x 200mm D x 216mm H)
Payload Range: 500 - 800 lb (226.8 - 362.9 kg)
- Vertical natural frequency of 1/2 Hz or less can be achieved over the entire load range.
- Horizontal natural frequency is load dependent. 1/2 Hz or less can be achieved at or near the nominal load.
