Sehan HD081-B 无绳螺丝刀

Type: Combined Screwdriver

Motor Type: Brushless DC Motor

Power Supply Type: Separated Controller

Operating Status: Manual

Torque: 3...8kgf.cm

No-Load Speed: 1000...1700 revolutions per minute (RPM)

Speed Control Type: Controlled by Controller

Torque Control Type: Controlled by Controller

Type of Bit: Hex 5mm

Size of Bit: 5mm

Startup Type: Lever

Design: Straight

Protection Function: Standard

Power Supply: 35VDC, 40VDC

Protection Current: Overheat, Overvoltage, Overload

Air Pressure: 4.5...6Bar

Torque Accuracy: 20%

Torque Repeatability: 3%

Rotation Direction: Clockwise, Counterclockwise

Display Type: LED Light Indicator

Displayed Information: Error

Function: Angle Control, Auto Reverse, Fastening Quality Control, Multi-Sequence, Screw Counting, Shockless Clutch, Soft Start

Connection Type with Controller: Wire

Working Environment: Dry

Relative Weight: 440g

Overall Width: 244.2mm

Standard Accessories: Bit, Control Cable

Compatible Product: Controller: HDC - 40i.
