UNI-T IT6722 可编程直流电源 (1 chanel, 80V, 20A, 400W)

- Channel : 1

- Output Rating: Voltage: 0~80V;0~20A;400W

- Load Regulation

Voltage:   <0.01%+10mV

Current:  <0.1%+5mA

- Line Regulation

Voltage:  <0.01%+2.5mV

Current:  <0.1%+2.5mA

- Programming Accuracy

Voltage:  <0.01%+20mV

Current:  <0.1%+10mA

- Read back Accuracy

Voltage:  <0.01%+20mV

Current:  <0.1%+20mA

- Ripple

Voltage:  <50mVrms

Current:  <15mArms

- Display: Screen : VFD

- Dimension (W*H*D): 214.5mm×88.2mm×354.6mm

- Weight Net:  4kg

- List & delayer: Yes, 9×150

- Input: AC:220(±10%)V

- Remote compensation:  1V

- Protocol: SCPI

- Interface: Remote: USB Device, RS232, GPIB

Details

Datasheet
